Mechanical Products 1480-123-200 20A Circuit Breaker Panel Mount Series 14 Thread Screw
Special Price
$9.16
Regular Price
$9.35
In stock
SKU
1480-123-200
Mechanical Products 1480-123-200 20A Circuit Breaker Panel Mount Series 14 Thread Screw is available to buy in increments of 1
Mechanical Products 1480-123-200 20A Circuit Breaker Panel Mount Series 14 Thread Screw
Mechanical Products 1480-123-200 20A Circuit Breaker Panel Mount Series 14 Thread Screw
Voltage: 250VAC / 50VDC
I.R.: 1k 250 / 50VDC A at VAC
3kA at 32VDC
Reset Mechanism: Type III, Manual Reset
Button: White button with black ampere rating stamp.
Mounting: Panel mount - includes Pal nut & Knurl nut.
Screw Terminals: Includes screws & lock washers.
Options: Weatherproof boot (refer below)
Pack Size: Stock lines 1pc,
Approvals: (all ratings)
(3A & 4A at 250VAC/50VDC)
(5A to 20A at 250VAC/50VDC)
Spare Pack (SP):
Contains 1pc of one rating
(1480-103-xxx series only).
For extended circuit
breaker amperage ranges
500mA through to 70A
please contact sales for
information.
Mechanical Products Series 14 Circuit Breakers (1480-123) – CIRCUIT BREAKER 20A 250VAC/50VDC PANEL MOUNT MANUAL RESET 3/8"-27 THREAD, SCREW
Features
- Miniature size, suitable for panel mount or dash mount
- Wide range of common amperages (3A-40A) for both AC and DC voltages
- Custom versions available with alternative termination, mounting, button and reset options
- Build-your-own 4, 6 or 8 way switch and circuit breaker panels
Specifications
| Part Number | 1480-123-200 |
|---|---|
| Description | CIRCUIT BREAKER 20A 250VAC/50VDC PANEL MOUNT MANUAL RESET 3/8"-27 THREAD, SCREW |
| Voltage | 250VAC / 50VDC |
| Interrupt Rating (I.R.) | 1kA at 250VAC / 50VDC, 3kA at 32VDC, OL1 rated |
| Ampere Range | 3A-40A |
| Reset Mechanism | Manual Reset |
| Button | White button with black ampere rating stamp |
| Mounting | Panel mount, includes Pal nut & Knurl nut; dash mount; snap mount upon request |
| Terminals (Quick Connect) | 1/4" (0.250 x 0.032") straight terminals |
| Terminals (Screw) | 3A-20A (#6-32), 25A-40A (#8-32); includes screws & lock washers |
| Bushing | 3/8"-27 or 7/16"-28 |
| Features | Ignition Protected, UL |
| IP Rating | IP67 |
| Options | Alternative ampere ratings (500mA-2.5A & 45A-70A) |
| Hardware Materials | Aluminum (small knurl nut, pal nut, name plate); Black Nylon (large knurl nut) |
| Manufacturer | Mechanical Products |
|---|
