Mechanical Products 19M-P10-B-090 Panel Mount Circuit Breaker 1/4' Stud Manual 90A 30VDC
Special Price
$91.63
Regular Price
$93.50
In stock
SKU
19M-P10-B-090
Mechanical Products 19M-P10-B-090 Panel Mount Circuit Breaker 1/4' Stud Manual 90A 30VDC is available to buy in increments of 1
Mechanical Products 19M-P10-B-090 Panel Mount Circuit Breaker 1/4' Stud Manual 90A 30VDC
Mechanical Products 19M-P10-B-090 Panel Mount Circuit Breaker 1/4' Stud Manual 90A 30VDC
I.R. (25A - 150A): 2.5kA at 14VDC, 1.5kA at 28VDC
I.R. (175A - 200A): 2.5kA at 30VDC
Reset Mechanism: Type III ( Manual Reset).
Button (Standard): Red with white ampere marking.
Button Options: None, Red, Red LED or Clear LED. All buttons feature a white ampere marking.
Panel Mounting Options:
Standard Thru-hole, no nuts (19M-P10) or
2 x # 10-32 fitted nuts (19M-P11).
Terminal Hardware: Includes 1/4” stainless steel sems nuts.
Threaded Stud: 1/4”-28 (12.5mm long)
Pack Size:1 pc
Housing: UL 94-V0 rated black thermoplastic.
Operating Temp: -40 deg. C to 85 deg. C
Vibration Rating: 10g per MIL-STD-204, Test Condition A.
Options: Type I - Automatic Reset version available.
Red or clear illuminated button versions available (tripID). Wide mounting plate version available. Contact sales for information.
Notes: Contact sales for dimensions, electrical & trip specifications for different styles of breaker.
Mechanical Products Series 19 Circuit Breakers (19M-P10) – CIRCUIT BREAKER 90A 30VDC PANEL MOUNT 1/4" STUD MANUAL
Features
- Wide range of ratings from 25A to 200A
- Superior ingress protection, rated IP67 & IP69K
- Designed for harsh applications up to 30VDC
- Optional LED indicator version for tripped circuits
- Front panel or rear panel mounting options
Specifications
| Part Number | 19M-P10-B-090 |
|---|---|
| Description | CIRCUIT BREAKER 90A 30VDC PANEL MOUNT 1/4" STUD MANUAL |
| Voltage | 30VDC |
| Ampere Rating | 25A, 30A, 35A, 40A, 45A, 50A, 60A, 70A, 80A, 90A, 100A, 105A, 120A, 135A, 150A, 175A, 200A |
| I.R. (25A - 150A) | 2.5kA at 14 VDC, 1.5kA at 28 VDC |
| I.R. (175A - 200A) | 2.5kA at 30VDC |
| Housing | UL 94-V0 rated black thermoplastic |
| Operating Temp | -40°C to 85°C |
| Approvals | SAE J1625, SAE J1171, ABYC E-11, UL 1077, MIL-STD-202 (101, 106, 213), MIL-STD-204 |
| Mounting | P10 thru-hole, no hex nuts; P11 2 x #10-32 fitted hex nuts; threaded stud 1/4"-28 (12.5mm long) includes 1/4" stainless steel sems nuts |
| IP Rating | IP67 & IP69K |
| Manufacturer | Mechanical Products |
|---|
