Bussmann FMG-116 Megafuse Fuse Block 500A M8 Studs
Special Price
$25.87
Regular Price
$26.40
In stock
SKU
FMG-116
Bussmann FMG-116 Megafuse Fuse Block 500A M8 Studs is available to buy in increments of 1
Bussmann FMG-116 Megafuse Fuse Block 500A M8 Studs
Bussmann FMG-116 Megafuse Fuse Block 500A M8 Studs
Rating: 300A
Body: Black UL rated 94V-0 thermoplastic
Accessories: Includes cover & sems nuts.
Studs: M8 threaded, zinc plated steel studs.
Cover: Black thermostatic elastomer (optional red cover).
Pack Size: 1
Bussmann FMG Fuse Blocks for AMG/MEGA fuses with Extended Cover – FUSE BLOCK 500A EXTENDED COVER M8 STUDS FOR MEGA FUSE
Features
- High current Mega fuse block for battery and alternator connections
- Interlocking pins allow connecting additional fuse holders for multi-fuse applications
- Cables can be routed to studs from nearly any direction (32V block)
- Both covers feature end cut-outs for wiring (32V block)
Specifications
| Part Number | FMG-116 |
|---|---|
| Description | FUSE BLOCK 500A EXTENDED COVER M8 STUDS FOR MEGA FUSE |
| Voltage Rating | 70VDC |
| Current Rating | 500A |
| Body & Cover | Black glass filled thermoplastic |
| Studs | M8 threaded |
| Torque Rating | 5 Nm |
| Agency Approval | VS-005002/VS-005005 |
| Note | Fuse not included |
| Voltage Rating (32V Block) | 32VDC |
| Current Rating (32V Block) | 500A |
| Body (32V Block) | Black UL rated 94V-0 thermoplastic |
| Cover (32V Block) | Black flexible thermoplastic elastomer; red cover optional |
| Wire Size (32V Block) | #8 AWG / 8mm² |
| Studs (32V Block) | Plated steel studs, 5 Nm torque rating |
| Approvals (32V Block) | RoHS |
| Manufacturer | Bussmann |
|---|
